Diamond dot peen marking
- Diamond peen marking machines are made with best technology and software support to mark Logo,part number on the finished components. We make two versions of peen marking - Fixed stand type with additional table top PC (with optional rotary head) and Portable peen marking with controller inbuilt. Both systems accept air pressure of 0.4 Pa to 0.6 Pa for better depth control.
Previous
Next
Specifications
- Working Area: 140mmX90mm
- Marking speed: 30mm to 40mm per second
- Repeatability: 0.01mm
- Marking depth: 0.1mm~0.5mm (According to material)
- Air pressure required: 0.2Mpa~0.6Mpa (2-4 bars)
- Power supply: AC 220V 50Hz
- Chuck dia: 100mm (Rs.40,000/- extra) Optional
- Marking type: All English Alphabets, all numbers, variety graphics, logos & barcodes
- System OS requirement: Windows 7- 32bit
- Mounting table optional
DIAMOND METAL MARKING LASER MACHINE (FIBER)
- Fiber laser marking are low power systems that work upto 100 watts.This is only suitable for marking on metals.Since the beam thickness is 0.1 mm, any complicated and intricate images, intricate font sizes can me marked with best clarity and legibility. The rotary head may also be used to mark on any circular or round components with radial surface. This system is most suitable for marking on tool holders, gold jewellery, designing on stainless steel utensils and cutting silver jewellery.
Previous
Next
Specifications
- Model : DLM-20F / DLM-30F / DLM-50F
- Working area X/Y - mm : 110x110 / 200x200 / 300x300
- Laser power : 20 W / 30 W / 50W
- Total Power: <0.5W
- Laser Wave Length : 1064nm
- Power supply : AC 220V/50Hz~60HZ
-
Depth marking and cutting : <.5mm(depth according to the no. of passes)
- Graphic format supported : Advertising industry ,Carved gifts and crafts industry ,Packing and printing industry, Leather clothing industry,Architectural model industry .
- Software support : EZCAD
DIAMOND CO2 LASER
- CO2 laser cutters are the most popular machines for small business entrepreneurs. The utility depends on the power of the CO2 laser tube. This machine is specifically for marking and cutting of non-metal materials.It can be used to cut Wood, MDF, ABS, Acrylic, Fabric, Plastic, Bamboo,Leather, Paper which is widely used in industrial, manufacturing applications and in the advertisement sectors.
Previous
Next
Specifications
- Model : DLC6090 / DLC1390 / DLC1325
- Working area X/Y - mm : 600X900 / 1300x900 / 1300x2500
- Laser power : 60 W / 80W / 100W / 130W /150W
- Cooling mode : CW3000 / CW5000/ CW5200
- Control Software : RD works V8, Compatible to CorelDraw, AutoCAD, Photoshop
- Power supply: AC 220V 50Hz
- Auxiliary Device :Exhaust fan and Exhaust pipe
- Applications : Advertising industry ,Carved gifts and crafts industry ,Packing and printing industry ,Leather clothing industry,Architectural model industry.
